Type: BF-I-013
Volume: 1200MMX1100MMX1750MM
Weight: 80KG
Power supply: 12V
Training project:
The structure of the remote control system;
The composition structure of the comfort system;
Remote matching;
Reading and clearing of fault codes of comfort system;
Feature
1. The audio-visual board is equipped with Cruze remote control system circuit and remote control, signal receiver, remote control computer and other components, and they are organically connected together.
2. The Cruze door lock on the audio-visual board is connected to the remote control host, and the door lock can be opened and closed with the remote control button.
3. The two ends of the circuit of the four Cruze door locks and one trunk lock on the audio-visual board are equipped with LED lights, and the current direction of the motor can be judged according to the lighting and extinguishing of the LED lights.
4. Equipped with OBD
5. Can read the fault code and data stream of Cruze remote control and comfort system
6. It can be matched with the remote control of Cruze car.
Training Contents
Theory teaching
1. Cruze key structure and remote control signal transmission.
2. The wireless signal reception of the Cruze remote control host.
3. Connection between Cruze remote control and comfort system network bus.
Training project:
1. There is a match between the Cruze remote control and the remote control host;
2. Cruze remote control door lock motor work test;
3. Set and cancel the setting and troubleshooting of the Cruze remote control, door lock and comfort system faults.
